Productdetails
Plaats van herkomst: China
Merknaam: LINK-PP
Certificering: UL,ROHS,Reach,ISO
Modelnummer: HR911102A
Betaling & het Verschepen Termijnen
Min. bestelaantal: 50/500/1000
Prijs: Supportive
Verpakking Details: 50PCS/Tray, 1200pcs/Carton
Levertijd: Voorraad
Betalingscondities: TT, NET30/60/90-Dagen
Levering vermogen: 4600K.PCS/Month
Specificatie: |
HR911102A |
Deel no: |
LPJ4025FBNL |
Ethernet: |
1x10/100Mbit |
Indicator: |
GY LEDs |
Montage: |
R/A schild |
monsters: |
Beschikbare vrij |
Specificatie: |
HR911102A |
Deel no: |
LPJ4025FBNL |
Ethernet: |
1x10/100Mbit |
Indicator: |
GY LEDs |
Montage: |
R/A schild |
monsters: |
Beschikbare vrij |
Elektrospecificaties @25℃
1.Turns verhouding:
TX=1CT: 1 RX=1CT: 1CT
2.Inductance: 350uH min
@100KHz, 100mVrms, 8 mA gelijkstroom bias
3.Insertion verlies:
1~65MHz: - MAXIMUM 1.0dB
4.Return verlies (dB min):
1~30MHz: - 18 40MHz: - 16
50MHz: - 12 60MHz: - 10
5.Crosstalk (dB min):
30MHz: - 40 60MHz: - 35
100MHz: - 30
6.CMR: (dB min):
30MHz: - 30 60MHz: - 20
100MHz: - 20
7.Hipot: 1500Vrms
8.Operating temperatuur: -40℃~+85℃.
