Productdetails:
Betalen & Verzenden Algemene voorwaarden:
|
| PN: | 0826-1G4T-32-F | Made in China: | Sm-LPJK44036AWNL |
|---|---|---|---|
| Toepassing: | 1000Base-t | Ethernet: | JOL Ethernet |
| Poort: | 1,2,4 Flexibele haven | HiPot: | 1500v |
| Hoogtepunt: | multihavenschakelaar,modulaire hefbomen rj45 |
||
|
0826-1g4t-32-F Bels |
||||||||||||||||||||||||||||||||
|
Handelaarartikelnummer |
0826-1g4t-32-F Bels |
|
||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Gemaakt in China |
Sm-LPJK44036AWNL |
|||||||||||||||||||||||||||||||
|
Fabrikant |
Verbinding-pp China |
|||||||||||||||||||||||||||||||
|
Beschrijving |
Gigabitrj45 Hefboom W/LED |
|||||||||||||||||||||||||||||||
|
Documenten |
PDF/3D/Step/IGS/Price/Cross |
|||||||||||||||||||||||||||||||
|
Beschikbare hoeveelheid |
2.000 PCs of 4 weken |
|||||||||||||||||||||||||||||||
0826-1g4t-32-F Elektrospecificaties @25℃
1.Turn verhouding (2%):
1CT∶1
2.Inductance OCL: 350uH min
@100KHz, 0.1V, Bias van 8mA gelijkstroom
3.Insertion verlies:
-1.0dB MAXIMUM @ 1~100MHz
-1.2dB MAXIMUM @ 100~125MHz
4.Return verlies (@100Ω):
-18dB MIN @ 1~30MHz
-16dB MIN @ 30~60MHz
-12dB MIN @ 60~80MHz
-10dB MIN @ 80~100MHz
5.Cross bespreking:
-30dB MIN @ 1~100MHz
6.Common wijzeverwerping:
-30dB MIN @ 1~100MHz
7.Hipot test: 1500Vrms min
8.Operatingt temperatuur: 0 AAN 70℃. /40 AAN 85℃.
