Productdetails
Plaats van herkomst: Guangdong, Huizhou
Merknaam: LINK-PP
Certificering: REACH, RoHS, FCC
Modelnummer: LPJE686-0DNL
Betaling & het Verschepen Termijnen
Min. bestelaantal: 1 stks, gratis monsters
Prijs: $0.09-$0.8
Verpakking Details: Dienblad, Band & Spoel
Levertijd: 1-3 dagen
Betalingscondities: T/T, L/C, CAD/D/P, OA
Levering vermogen: 6000K-PCS/maand
Onderdeelnr.: |
LPJE686-0DNL |
Aantal poorten: |
Gestapelde 2x4 poorten |
Lengte: |
57.0 mm |
Breedte: |
27.0mm |
Hoogte: |
16.4 mm |
Bedrijfstemperatuur: |
– 40°C aan +85°C |
Onderdeelnr.: |
LPJE686-0DNL |
Aantal poorten: |
Gestapelde 2x4 poorten |
Lengte: |
57.0 mm |
Breedte: |
27.0mm |
Hoogte: |
16.4 mm |
Bedrijfstemperatuur: |
– 40°C aan +85°C |
The Vertical RJ45 2×4 Connector is designed for high-density Ethernet applications requiring stable signal transmission, durable mechanical performance, and long-term reliability. It is commonly used in network switches, communication equipment, industrial controllers, and embedded Ethernet systems.
| Parameter | Specification |
|---|---|
| Voltage Rating | 125V AC |
| Current Rating | 1.5A |
| Contact Resistance | ≤ 50 mΩ |
| Insulation Resistance | ≥ 500 MΩ @ 500V DC |
| Dielectric Strength | 1000V AC, 50/60Hz, 1 min |
| Parameter | Specification |
|---|---|
| Housing Material | Glass-Filled Polyester (PBT), Black, UL94V-0 |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Flash over Nickel |
| Shield Material | Copper Alloy with Nickel Plating, 0.20 mm thickness |
| Operating Life | ≥ 750 mating cycles |
| Parameter | Specification |
|---|---|
| Storage Temperature | –40°C to +85°C |
| Operating Temperature | –40°C to +85°C |
| Wave Solder Temperature | 250°C for 5 seconds |
| UL Certification | File No. E484635 |
