Productdetails
Plaats van herkomst: Guangdong, China
Merknaam: LINK-PP
Certificering: UL,RoHS,Reach,ISO
Modelnummer: 749013011A
Betaling & het Verschepen Termijnen
Min. bestelaantal: 400/2000/10k/25k
Prijs: $0.06-$0.9
Verpakking Details: T&R
Levertijd: 3-5 dagen
Betalingscondities: TT, net30/60/90 dagen
Levering vermogen: 3kk/maand
Onderdeelnummer: |
749013011A |
Categorie: |
LAN-transformator / Ethernet-magneten |
Montagetype: |
Oppervlaktebevestiging (SMT) |
Gegevenssnelheid: |
10/100BASE-TX |
POE -ondersteuning: |
Ja |
Bedrijfstemperatuur: |
-40 °C tot +105 °C |
Onderdeelnummer: |
749013011A |
Categorie: |
LAN-transformator / Ethernet-magneten |
Montagetype: |
Oppervlaktebevestiging (SMT) |
Gegevenssnelheid: |
10/100BASE-TX |
POE -ondersteuning: |
Ja |
Bedrijfstemperatuur: |
-40 °C tot +105 °C |
The 749013011A is a high-performance LAN transformer specifically designed for 10/100 Base-T Ethernet applications with Power over Ethernet (PoE) support. This SMT transformer provides signal integrity, electrical isolation, and efficient power transfer over Ethernet cables, fully compliant with IEEE 802.3 and IEEE 802.3af standards.
It is ideal for industrial automation, IP communication, and IoT applications where reliable Ethernet connectivity and PoE power delivery are required.
|
|---|
The 749013011A supports PoE operation with up to 350 mA current per center tap, allowing both data transmission and DC power delivery through a single Ethernet cable.
It is optimized for thermal reliability — ensuring stable performance up to +105°C component temperature under full PoE load.
