Productdetails
Place of Origin: CHINA
Merknaam: LINK-PP
Certificering: RoHS compliant
Model Number: 1840860-4
Betaling & het Verschepen Termijnen
Minimum Order Quantity: 1pcs，Free samples
Prijs: $1.2 - $3.5
Packaging Details: Tray
Delivery Time: About 3 Days
Payment Terms: TT, NET30/60/90 Days, Western Union
Supply Ability: 20K Pieces per Week
Number of Ports: |
Multiport RJ45 |
Series: |
2X6 |
Port Configuration: |
Stacked |
Application: |
Gigabit Ethernet |
EMI Tabs: |
With |
Operating Temperature: |
0°C ~ 70°C |
Number of Ports: |
Multiport RJ45 |
Series: |
2X6 |
Port Configuration: |
Stacked |
Application: |
Gigabit Ethernet |
EMI Tabs: |
With |
Operating Temperature: |
0°C ~ 70°C |
| Parameter | Specificatie |
|---|---|
| Onderdeelnummer | 1840860-4 |
| Toepassing | 10/100/1000BASE‑T |
| Impedantie | 100 Ω |
| Turns Ratio (Chip: Kabel) | 1:1 (Alle vier paren) |
| OCL (Open Circuit Inductantie) | ≥ 350 µH @ 100 kHz, 0,1 Vrms, 8 mA DC bias, 0–70°C |
| Bidirectionele paren | Alle vier paren |
| Invoegverlies (IL) | ≤ -1,1 dB (1–100 MHz) |
| Retourverlies (RL) | ≥ -18 dB (1–40 MHz); ≥ -12–20·log(f/80) dB (40,1–100 MHz) |
| Crosstalk-demping | ≥ -35 dB (1–40 MHz); ≥ -33–20·log(f/50) dB (40,1–100 MHz) |
| CMRR (Common Mode Rejection) | ≥ -30 dB (1–100 MHz) |
| Isolatiespanning | 2250 VDC, 60 sec, 500 V/sec stijging, alle poorten aangesloten |
De 2x6 gestapelde RJ45-connector met geïntegreerde magnetics wordt veel gebruikt in Ethernet-omgevingen met hoge dichtheid die betrouwbare, ruimte-efficiënte en snelle netwerkinterfaces vereisen. Typische toepassingen zijn:
