Productdetails
Plaats van herkomst: Guangdong, China
Merknaam: LINK-PP
Certificering: UL,RoHS,Reach,ISO
Modelnummer: XF-11FB-05ANL-SGI
Betaling & het Verschepen Termijnen
Min. bestelaantal: 400/2000/10K/25K
Prijs: $0.06-$3.2
Verpakking Details: T&R
Levertijd: Voorraad
Betalingscondities: TT, NET30/60/90-Dagen
Levering vermogen: 3KK/Month
P/n: |
XF-11FB-05ANL-SGI / XF-11FB-05ANL |
Radio aanzetten.: |
1: 1 |
Type: |
SMD |
Familie: |
10/100Mbps Transformer |
HAVEN: |
Enkele poort |
hipot: |
1500VDC |
P/n: |
XF-11FB-05ANL-SGI / XF-11FB-05ANL |
Radio aanzetten.: |
1: 1 |
Type: |
SMD |
Familie: |
10/100Mbps Transformer |
HAVEN: |
Enkele poort |
hipot: |
1500VDC |
| Parameter | Specificatie |
|---|---|
| Draaiverhouding (±2%) | 1CT : 1CT |
| OCL (100KHz/100mV @8mA) | 350 µH MIN |
| Invoegverlies (dB MAX) | -1.1 dB (0.3–100 MHz) |
| Retourverlies (dB TYP) | -20 dB (30 MHz), -14 dB (60 MHz), -11.5 dB (80 MHz) |
| Crosstalk (dB TYP) | -45 dB (30 MHz), -40 dB (60 MHz), -35 dB (100 MHz) |
| DCMR (dB TYP) | -42 dB (30 MHz), -37 dB (50 MHz), -33 dB (100 MHz) |
| Hi-Pot Test | 1500 Vrms/0.5mA/60 Sec OF 1650 Vrms/0.5mA/2 Sec |
| Bedrijfstemperatuur | -40℃ tot +85℃ |
| RoHS Conformiteit | JA |
